Aruba R7T05A AP-585 (RW) Unified Outdoor Access Points in Dubai, UAE

Be the first to review this product

Availability: Out of stock

Delivery : Allocation

Part No R7T05A

Purpose built to survive in the harshest outdoor
environments and extreme temperatures
(-40 to +65˚ C) with IP66/67 ratings
Ultimate Wi-Fi 6 performance and speed with a
maximum aggregate data rate of 2.97Gbps
Bluetooth and 802.15.4/Zigbee radios with
high power to meet demanding Industrial IoT
requirements
Dual redundant power/port failover and support
for AC ensure high availability with uninterrupted
performance
Backed by Aruba’s Limited Lifetime Warranty

Quote

Details

Aruba R7T05A AP-585 (RW) Unified Outdoor Access Points in Dubai, UAE

Purpose-built to survive in the harshest outdoor
environments, Aruba 580 Series Outdoor Access Points
are designed for the highest levels of performance and
greater deployment flexibility – all backed by a limited
lifetime warranty. Aruba 580 Series APs deliver the speed
and reliability needed for large enterprise and Industrial IoT
deployments with high power Bluetooth and 802.15.4/Zigbee
radios and flexible power options.

Specifications

Internet of Things (IoT)
Internet of Things (IoT) Compatible	Yes
Communications Technology	Bluetooth Low Energy (LE), Zigbee
Miscellaneous
Compliant Standards	IEC 60601-1-2, FCC, UL 60950-1, IEC 60950-1, EN 60950-1, EN 60601-1-2, IP67, IP66, IEC 60950-22, EMC 2014/30/EU, LVD 2014/35/EU, EN 50155, EN 62368-1, IEC 62368-1, ISED, UL 62368-1, RED 2014/53/EU, SIG
Networking
Form Factor	External
Connectivity Technology	Wireless
Data Transfer Rate	2.4 Gbps
Line Coding Format	OFDM, OFDMA
Data Link Protocol	IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, Bluetooth 5.0, 802.11ax
Spread Spectrum Method	DSSS
Frequency Band	2.4 GHz, 5 GHz
Performance	Maximum data rate (5 GHz): 2.4 Gbps ¦ Maximum data rate (2.4 GHz): 574 Mbps ¦ Aggregate data rate: 2.97 Gbps
Capacity	Associated client devices per radio: 1024
Features	DFS support, Trusted Platform Module (TPM), Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Advanced Cellular Coexistence (ACC), cyclic shift diversity (CSD), Intelligent Power Monitoring (IPM), High-Throughput (HT) support, 4x4:4 MU-MIMO technology, Very High Throughput (VHT) support, Target Wait Time (TWT), Advanced IoT Coexistence (AIC), Policy Enforcement Firewall (PEF), Layer 7 Deep Packet Inspection (DPI), Passpoint Release 2
Encryption Algorithm	WPA3, WPA3-Enhanced Open, WPA2-MPSK
Manufacturer Warranty
Service & Support	Limited warranty - lifetime
Environmental Parameters
Min Operating Temperature	-40 °F
Max Operating Temperature	149 °F
Humidity Range Operating	5 - 93% (non-condensing)
General
Device Type	Wireless access point
Ruggedized Design	Outdoor
Width	12.8 in
Depth	12.3 in
Height	12.6 in
Weight	11.55 lbs
Expansion / Connectivity
Interfaces	1 x 5GBase-T - RJ-45 ¦ 1 x 10GBASE-SR - SFP+ ¦ 1 x 1000Base-T (PoE) ¦ 1 x console - USB-C
Dimensions & Weight (Shipping)
Shipping Width	17 in
Shipping Depth	16.3 in
Shipping Height	17.4 in
Shipping Weight	17.22 lbs
Power
Power Over Ethernet (PoE) Supported	PoE Class 6
Voltage Required	AC 110/240 V
Power Consumption Operational	71 Watt
Antenna
Antenna	Internal
Antenna Qty	4
Directivity	Omni-directional
Software / System Requirements
OS Required	ArubaOS, InstantOS

More Information

More Information
Part No	R7T05A
GTIN-/EAN-Code	0190017514369
UPC	190017514369
Country of Manufacture	China
Brand	Aruba Networks
Data Transfer Rate	2.5 Gbps to 3 Gbps
Application	Outdoor
Antennas	Internal
