10/100/1000T to SFP Dual Port Media Converter

Expected dispatch on : May 07 - 08

Part No AT-GS2002/SP-60

Allied Telesis 10/100/1000T to SFP Dual port Media Converter

The AT-GS2002/SP Ethernet Bridging Converters are designed to extend the distance of your network by interconnecting LAN devices that are physically separated by large distances. These bridging converters have the functionality to connect any managed/unmanaged 10Mbps, 100Mbps, or 1000Mbps (1Gbps) switch or hub using standard 10/100/1000T RJ45 connections and convert the electrical signal to fiber opticalsignal via its SFP port.

Quote

Details

10/100/1000T to SFP Dual Port Media Converter

Extend the Distance of Ethernet
Each AT-GS2002/SP bridging converter features a 10/100/1000T twisted pair port and an SFP port. The twisted pair port has an RJ45 connector and a maximum operating distance of 100 meters (328 feet). These units can operate at half- and full-duplex.

Standalone or Rackmounted
Each small bridging converter is powered by an external power supply unit for use in standalone applications. Where multiple media
converters are used, up to 12 standalone devices can be inserted into a low-cost AT-MCR12 rackmount chassis, allowing all the converters to be powered by a single internal power supply. In critical applications, a second load sharing internal power supply can be
installed into the rackmount chassis.

Hassle Free Support
All Allied Telesyn Ethernet bridging converters have a limited lifetime warranty and free technical support, ensuring trouble-free
installation.
