Aruba AP 22 (RW) 2x2 Wi-Fi 6 Indoor Access Point

Aruba Instant On
Expected dispatch on : 0May 24 - 25
Part No R4W02A

Instant On AP22 (RW) 2x2 Wi-Fi 6 Indoor Access Point

  • Wi-Fi 6 for high performance and efficiency.
  • Supports up to 75 associated clients per radio.
  • Support for WPA2/WPA3 protected employee and guest login with Enhanced Open for per user guest access.
AED 404.25
Inclusive of 5% VAT


Aruba AP 22 (RW) 2x2 Wi-Fi 6 Indoor Access Point

Aruba Instant On AP22 Indoor Access Points delivers affordable, business-grade 802.11ax Wi-Fi for high-performance, high-density small business environments. Business-grade capabilities are designed to meet the growing number of mobile, IoT, and security needs.

The compact form factor of the Aruba Instant On AP22 Indoor Access Points (AP) delivers multi-user capabilities and a maximum aggregate peak data rate of 1.2 Gbps for high-definition video streaming and cloud application requirements. Everything from mounting hardware to easy-to-use web and mobile app management tools and business-grade software features is included – no extra charge or need for external controllers.


Everything you need at one all-inclusive price

Get all the hardware and security your network needs, with no subscription or licensing fees. Grow your network as your business grows. Start strong with included hardware coverage and 24/7 concierge-level phone support.

  • 24-month warranty for access points
  • 24 X 7 telephone support for the first 90 days
  • 24 X 7 chat support
  • Software support
  • Free next-business-day shipping for all replacement parts



Certifications EN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments) Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3

Input Voltage Power over Ethernet (POE): 802.3af (class 3) DC power (12V) Note: Power sources are sold separately

Wi-Fi Antenna Integrated down-tilt omni-directional antennas for 2x2 MIMO with a peak antenna gain of 4.3dBi in 2.4GHz and 5.6dBi in 5GHz (of the effective, combined pattern for both antennas in each band).

Connectivity IEEE 802.11ax

External I/O Ports (1) uplink Gigabit Ethernet port, with POE-in support (802.3af)

Mounting The access point ships with a white mount clip that can attach to both wall and ceiling. You can also purchase a mount (R6P90A) that matches the aesthetic design and looks of the APs, to blend seamlessly into your environment.

Power Consumption Description Max power consumption (worst-case): 10.1W (PoE), 8.8W (DC)

Radio Coverage Dual Radio for simultaneous dual-band operation 5 GHz 802.11ax 2x2 MIMO for up to 1.2 Gbps wireless data rate, with Multi User MIMO support (Wi-Fi 6) 2.4 GHz 802.11ax 2x2 MIMO for up to 574 Mbps wireless data rate (Wi-Fi 6)

Built-In Security Gateway/Firewall
When it comes to stopping people and bots from accessing your network from the outside it’s critical for small businesses. We’ve added advanced features that do not require external gateways and the complexity that comes with them. In case of gateway failure, you can quickly and easily swap it out with another AP in a single click.

App Visibility And Control
Get full visibility into the apps running on your network along with the ability to block certain applications from being used. You also get the flexibility to turn off this feature from the mobile app as well.

Easy Guest Access
Customize the experience with your logo, authentication, rules of use or keep it simple. Applying bandwidth rates, setting data usage per app and limiting duration of use is also a breeze. Or use an external portal or service like Facebook Wi-Fi. You can also have open guest networks for quick and easy access.

Enterprise Grade Wi-Fi
Keep users happy as they move between spaces or meetings with a seamless handoff between APs. All you need is to use is secure WPA2 or WPA3 authentication on your secure networks and we do the rest. You can also control the network width, channels and channel width to suit your specific environment in a single click.

Multi-Site Management
The cloud-hosted web interface and mobile app make it easy to manage multiple sites: multiple networks, distributed deployments and multi-tenancy deployments. Each site is logically separated and has its own configuration, statistics, guest portal, and admin read/write and read-only privileges.

PPPoE And Static IP
Every customer has different environment. They might want to authenticate with the ISP’s PPPoE server and provide static IP to the APs.

Smart MESH
Each of the Aruba Instant On APs support extending coverage to those hard to reach spaces where Ethernet cabling may not exist. The Aruba Instant On mobile app makes it easy to have a Mesh network up in minutes – indoor or out.

5 Star voice and video quality
Wi-Fi Alliance Certified Instant On APs automatically detect and prioritize applications such as Skype, FaceTime and WeChat that use SIP, SCCP and other popular protocols. Now it’s even easier to use softphones and the mobile apps that keep your users connected.


More Information

More Information
Part No R4W02A
GTIN-/EAN-Code 0190017445397
UPC 190017445397
Country of Manufacture China
Brand Aruba Instant On
Data Transfer Rate 1.6 Gbps to 2 Gbps
Application Indoor
Antennas Internal
Ports 1

Reviews 2

Write Your Own Review
Your Rating
You're reviewing:Aruba AP 22 (RW) 2x2 Wi-Fi 6 Indoor Access Point


More Information

K Walton | Verified Purchase | 05/02/2022
Excellent coverage, stability, and the wireless mesh work great. Very easy set-up and user management system. I totally recommend if you want to leave wifi issues in the past.

Mark | Verified Purchase | 05/02/2022
If you want Wifi6 and you are coming from a single WIFI router or a powerline setup, they are great, and easy to set up. You lose some of the more advanced capabilities you may find in corporate-level WIFI solutions such as Unifi. Also, these are only 2x2 MIMO so are not as powerful as, say, 3x3 or 4x4 Wifi5 points like the Unifi.
